ISMEditorGraphPropertyNodeInterface¶
Module: SMSystem
#include <ISMEditorGraphPropertyNodeInterface.h>
Inherited by USMGraphK2Node_PropertyNode_Base
Description¶
Interface for accessing editor graph properties from non-editor modules.
Public Functions¶
| Name | |
|---|---|
| FLinearColor | GetHighlightColorFromSeverity(const ESMLogType InSeverity) |
| virtual void | SetHighlight(bool bEnable, FLinearColor Color =FLinearColor(1.f, 0.84f, 0.f, 1.2), bool bClearOnCompile =false) =0  |
| virtual void | SetNotification(bool bEnable, ESMLogType Severity =ESMLogType::Note, const FString & Message =TEXT(""), bool bClearOnCompile =false) =0  |
| virtual void | SetNotificationAndHighlight(bool bEnable, ESMLogType Severity =ESMLogType::Note, const FString & Message =TEXT(""), bool bClearOnCompile =false) =0  |
| virtual void | ResetProperty() =0  |
| virtual void | RefreshPropertyPinFromValue() =0 |
| virtual void | RefreshPropertyValueFromPin() =0 |
Public Functions Documentation¶
function GetHighlightColorFromSeverity¶
Return the highlight color to use based on the severity.
Parameters:
InSeverity- The severity log type.
Return: The hard coded linear color matching the severity.
function SetHighlight¶
virtual void SetHighlight(
bool bEnable,
FLinearColor Color =FLinearColor(1.f, 0.84f, 0.f, 1.2),
bool bClearOnCompile =false
) =0
Highlight a property on the owning graph node.
Parameters:
bEnable- Enable or disable the highlight.
Color- The color of the highlight.
bClearOnCompile- If the highlight should clear when the owning state machine blueprint is compiled.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::SetHighlight
function SetNotification¶
virtual void SetNotification(
bool bEnable,
ESMLogType Severity =ESMLogType::Note,
const FString & Message =TEXT(""),
bool bClearOnCompile =false
) =0
Show a notification icon on the property.
Parameters:
bEnable- Show or hide the notification.
Severity- The severity of the log type.
Message- The tooltip to display when hovering the icon.
bClearOnCompile- If the notification should clear when the owning state machine blueprint is compiled.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::SetNotification
function SetNotificationAndHighlight¶
virtual void SetNotificationAndHighlight(
bool bEnable,
ESMLogType Severity =ESMLogType::Note,
const FString & Message =TEXT(""),
bool bClearOnCompile =false
) =0
Show a notification icon and highlight the property based on the severity.
Parameters:
bEnable- Show or hide the notification and highlight.
Severity- The severity of the log type.
Message- The tooltip to display when hovering the icon.
bClearOnCompile- If the notification and highlight should clear when the owning state machine blueprint is compiled.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::SetNotificationAndHighlight
function ResetProperty¶
Reset the property back to the class defaults, completely resetting the graph.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::ResetProperty
function RefreshPropertyPinFromValue¶
Refresh an exposed property's blueprint pin on the UEdGraphNode from the property's current value. This can be used if you programmatically update an exposed property outside of editor construction scripts such as through PostEditChangeProperty and want that value reflected on the node.
Warning:
This should NOT be called during editor construction scripts as they will automatically refresh property pins.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::RefreshPropertyPinFromValue
function RefreshPropertyValueFromPin¶
Refresh an exposed property value from the matching pin on the UEdGraphNode. This can be used if you need to make sure the current value in C++ matches what is entered into the blueprint pin.
Warning:
This should NOT be called during editor construction scripts as they will automatically refresh property values.
Reimplemented by: USMGraphK2Node_PropertyNode_Base::RefreshPropertyValueFromPin
